EFD1000 E5 Dual Electronic Flight Instrument (EFI) Install Manual
DOCUMENT # 900-00041-001 PAGE 137-226 REVISION D
© Copyright 2019 Aspen Avionics Inc.
EXAMPLE:
EXAMPLE:
INSTALLATION MENU PAGE 9 – ACU CONFIG
SW v1.0
Feature
Options
Actual Setting
ACU HSI TYPE
0,1 (0=KI525A, 1=NSD360)
ACU FD TYPE
0,1,3,4 (0=NONE,1=KI256, 3=G550)
ACU DATUM
NORMAL, REVERSED
FD PITCH OFFSET ADJ
-10.0 to +10.0 (degrees)
FD ROLL OFFSET ADJ
-10.0 to +10.0 (degrees)
Notes:
Installation Date:
Aircraft Model:
EFD1000 S/N:
Aircraft Type:
RSM S/N:
Aircraft S/N:
ACU S/N:
CM S/N:
Record Aircraft and Equipment Data
Record installation as configured and wired
