1.3 Optional LRU Install Kits
Installation Kit, ACU P/N 903-00003-001
Part Number
Description
Quantity
116-00014-001
15 pin D-Sub connector
1
116-00014-002
25 pin D-Sub connector
1
116-00014-003
37 pin D-Sub connector
1
116-00026-002
DB15 EMI Back shell
1
116-00026-003
DB25 EMI Back shell
1
116-00026-005
DB37 EMI Back shell
1
116-00015-001
Crimp Sockets
77
Table 1-7: 903-00003-001 ACU Install Kit
Installation Kit, ACU2 P/N 903-00003-002
Part Number
Description
Quantity
116-00014-001
15 pin D-Sub connector
1
116-00014-002
25 pin D-Sub connector
1
116-00014-003
37 pin D-Sub connector
1
116-00052-001
62 pin high density D-Sub connector, contacts, back shell
1
116-00026-002
DB15 EMI Back shell
1
116-00026-003
DB25 EMI Back shell
1
116-00026-005
DB37 EMI Back shell
1
116-00015-001
Crimp Sockets
77
Table 1-8: 903-00003-002 ACU2 Install Kit
Installation Kit, EA100 P/N 903-00011-( )
Part Number
Description
Quantity by Kit Variant
-001
-002
-003
-004
116-00022-002
44 Pin HD D-Sub connector with contacts
1
1
1
1
116-00026-001
DB 25 EMI Metal Back shell
1
1
1
1
116-00014-001
15 pin D-sub connector
1
1
1
1
116-00026-007
DB15 EMI Back shell
1
1
1
1
116-00015-001
Crimp Sockets
15
15
15
15
122-00031-001
Diode Junction Splice, 200v
2
2
2
2
403-00009-001
Century II/III/IV supplemental parts
bag:
2ea. 126-00004-006 Cap 0.12uF. 400V
2ea. 132-00007-002 Resistor 1.21KΩ, 1/4W, 1%
2ea. 132-00007-004 Resistor 2.2KΩ, 1/4W, 1%
1
1
1
1
412-00013-001
EA100 10ft Ethernet Cable
-
1
-
-
412-00013-002
EA100 20ft Ethernet Cable
-
-
1
-
412-00013-003
EA100 30ft Ethernet Cable
-
-
-
1
Table 1-9: 903-00011-( ) EA100 Install Kits
