Aspen Avionics EFD1000 E5 - 8.1.5 ARINC 429 VLOC Input; 8.1.6 ARINC 429 Output

EFD1000 E5 Dual Electronic Flight Instrument (EFI) Install Manual
DOCUMENT # 900-00041-001 PAGE 87-226 REVISION D
© Copyright 2019 Aspen Avionics Inc.
ARINC Label(s)
EFD Parameter
Label 117
GPS “Vertical Deviation”
Label 147
GPS “Magnetic Variation”
Label 121
GPS “Horizontal Command”
Label 251
GPS “Distance to Go”
Label 252
GPS “Time to Go”
Label 275, bit 23
GPS “TO” Flag
Label 275, bit 24
GPS “FROM” Flag
Label 312
GPS “Ground Speed”
Label 313
GPS “Track”
Label 326
GPS “Lateral Deviation Scale Factor” full precision
Label 327
GPS “Vertical Deviation Scale Factor” full precision
Table 8-2: EFD A429 GPS Input
8.1.5 ARINC 429 VLOC Input
The EFD receives the following labels on Pins (18, 19) and (22, 23) when transmitted from
a VLOC receiver. The VLOC input ports can be configured either HIGH or LOW.
ARINC (Label)
EFD Parameter
Label 34
Tuned Frequency
Label 34, bit 14 set
ILS Energize
Label 173
Localizer deviation and validity flags
Label 174
Glide Slope deviation and validity flags
Label 222
VOR Omni bearing
Table 8-3: EFD A429 VLOC Input
8.1.6 ARINC 429 Output
The EFD1000 E5 transmits the following labels on pins 26 and 27 (Note – some labels are
only transmitted when configured for an ACU installation). Labels 350 and 354 are
proprietary ACU labels and should not be used for any purpose by any other third party
device.
Note – When connecting any third party device to this output it is the installer’s
responsibility to verify that the connected device does not have any adverse effects from
the labels below.
Note – The labels below are non-standard ARINC or GAMA labels due solely to the rate at
which the label is being transmitted.
Note- Except as shown in the wiring diagrams (Section 9) no ARINC 429 interface is
approved under the Aspen STC, and must be approved separately.
ARINC Label
EFD Parameter
ARINC
Transmit Rate*
100
(1)
Selected Course
200ms
105
Heading Datum
50ms
173
Lateral Deviation
50ms
