EFD1000 E5 Dual Electronic Flight Instrument (EFI) Install Manual
DOCUMENT # 900-00041-001 PAGE 20-226 REVISION D
© Copyright 2019 Aspen Avionics Inc.
1.4 Accessories Required but Not Supplied – EFD1000 E5
Manufacturer’s P/N or Specification
Circuit Breaker pull to open (EFD) 7.5 amp
Circuit Breaker (ACU) 2 amp
EFD to GPS/ACU double shielded cable
Unshielded wire 24, 22, 20 AWG
3/16” pitot/static tube (EFD to T fitting
EFD Mounting Screws #6-32, 6 ea.
EFD Mounting Lock Nuts #6-32
ACU Mounting Lock Nuts #8-32
Table 1-10: EFD1000 E5 Accessories Required but Not Supplied
1.5 Optional Accessories Not Supplied – EFD1000 E5
Manufacturer P/N or Specification
E5 Master switch –rated for 7.5 amps cont.
Circuit Breaker/Switch 7.5amp
(optional – in lieu of separate C/B and switch)
*Tinned Copper Over Braid
*used in lieu of double shielded wire
MIL-SPEC# AA59569R36T0250 ¼”
MIL-SPEC# AA59569R36T0500 ½”
Installer fabricated per Section 6.9.5
RSM Shim
(may be required on extreme mounting angles)
Installer fabricated per Section 6.9.9
RSM sealant non-pressure vessel mounting
7 conductor shielded cable
For installer fabricated harness using
116-00020-001 connector.
M27500-A24SD7T23/
M27500-22TG7T14
Table 1-11: E5 Optional Accessories Not Supplied
1.6 Optional Accessories Required but Not Supplied – EA100
Manufacturer P/N or Specification
A/P AHRS FAIL press-to-test indicator
“dimmable cat’s-eye”
Electroswitch Electronic Products
MS25041-4 (dimmable)
(also available from Aircraft Spruce)
EA100 Ethernet Cable
(Cat 5e Ethernet cable (MX100P-24)
Order Aspen Avionics EA100
Installation kits 903-00011-002,
-003, or -004 which include the cable.
EA100 Mounting Lock Nuts #8-32 (6)
EA100 Mounting Washers (6)
EA100 Mounting Screw #8-32 (6)
Table 1-12: EA100 Optional Accessories Required but Not Supplied
