Figure 10-10: RSM Calibration Graphic
1
A
CR
2
B
CR
R
= Imaginary pivot point
R = Radius to pivot point – approximately equal to wingspan (≈30ft)
1 = Starting Point
A = Established Constant Rate turn ≈ 10 seconds after 1
CR = Constant Rate Turn must continue until end of 60sec timer
2 = 360º turn complete – continue at Constant Rate – Do not stop
B = 60sec timer must not reach Zero before this point
D = Accept/Reject CAL message occurs between B & D
CR
CR
CR
D
