1.1.2 AML-STC Document List
The following list of documents contain engineering aspects that are a part of AML-STC
SA10822SC data.
Document
P/N
Description
ICA
900-00012-001
Instructions for Continued Airworthiness
AFMS
900-00038-001
Airplane Flight Manual Supplement
Table 1-3: AML-STC Additional Document List
1.2 Installation Kit Contents
Installation Kit, EFD1000 - Basic P/N 903-00001-004
Part Number
Description
Quantity
403-00002-001
Panel Mounting Bracket Assembly
1
116-00022-002
44 Pin HD D-Sub Connector with Contacts
1
116-00026-006
EMI Metal Backshell
1
275-00001-002
Pitot Quick Connector
1
275-00001-001
Static Quick Connector
1
273-00003-001
Tee Fittings for Pitot/Static, 0.25” x 0.17” x 0.25”
2
271-00001-001
Miniature Hose Clamps
8
412-00004-001
Configuration Module Cable Assembly
1
Table 1-4: 903-00001-( ) EFD1000 EFD Install Kit
Optional EFD Recess Mount Kit P/N 903-00007-001
Part Number
Description
Quantity
903-00007-001
EFD Recess Mount Installation Kit (1 required per EFD)
1
Table 1-5: 903-00007-001 EFD Recess Mount Kit (optional)
Installation Kit, RSM P/N 903-00002-( )
Part Number
Description
Quantity by Kit Variant
-001
-002
-003
-004
412-00005-001
RSM 35ft cable assembly w/connector
1
1
-
-
412-00006-001
RSM 50ft cable assembly w/connector
-
-
1
1
201-00004-001
Screw, Machined, Pan, Phillips, Brass,
8-32 11/4”, MS35214-47
4
4
4
4
212-00001-001
Nut, Hex, Locking, Nylon Insert, Brass,
8-32, MS21044B08
4
4
4
4
231-00001-001
Washer, Flat, #8, Brass, 11/64” ID,
3/8” OD, NAS1149B0832H
4
4
4
4
256-00001-001
O-Ring, AS568A-120
1
1
1
1
403-00004-001
RSM Doubler Installation Assy
-
1
-
1
Table 1-6: 903-00002-( ) RSM Install Kits
