EFD1000 E5 Dual Electronic Flight Instrument (EFI) Install Manual
DOCUMENT # 900-00041-001 PAGE 197-226 REVISION D
© Copyright 2019 Aspen Avionics Inc.
E2 EA100 Specifications
General Specifications:
Part Number ...................... 910-00013-001
Width ................................ 6.83 in. including mounting flanges
Height ............................... 1.85 in.
Length ............................... 4.28 in.
Weight ............................... 1.25 lbs.
Operational Specifications:
Operating Temp ................ -20°C to +55°C
Storage Temp .................... -55°C to +85°C
Max Operating Altitude ..... 55,000 ft.
Cooling ............................. None Required
Max Humidity .................... 95% at 50°C
Input Voltage ..................... +14 and 28 VDC
Nominal Current ................ 0.25/0.5 Amps (28v/14v)
I/O Specifications:
Ethernet Port ..................... 1 Digital
Autopilot Pitch gyro Out .... 1 Analog
Autopilot Roll gyro Out ...... 1 Analog
Autopilot gyro Ref In ......... 1 Analog
AP Disc Relay ..................... 1 Output
ATT Fail Relay .................... 1 Output
Signal Output .................... Attitude Reference Signals (Roll and Pitch), configurable to
King and Century gyro levels.
Certification Specifications:
The EA100 is certified as a sub-component of the required EFD1000 system
Software:
RTCA DO-178B ................. Level C
Complex Electronic Hardware (CEH):
NONE
Environmental:
RTCA DO-160E ................. See Environmental Qualification Form this Appendix
