2.2 Remote Sensor Module (RSM)
2.2.1 General Specifications
Part Number ...................... 910-00003-002, (RSM, top mount), Rev E or later
910-00003-003, (RSM, bottom mount), Rev E or later
......................................... 910-00003-001, (RSM, top mount, Pro upgrade option), Rev
G or later
Width ................................ 2.65 in. (Measured at Base)
Height ............................... 1.1 in. maximum (Measured from Base)
Length ............................... 4.40 in. (Front to Rear)
Weight ............................... 0.5 lbs.
2.2.2 Operational Specifications
Operating Temp ................ -55°C to +70°C
Storage Temp .................... -55°C to +85°C
Max Operating Altitude ..... 55,000 ft. Unpressurized
Cooling ............................. None Required
Max Humidity .................... 95% at 50°C
Input Voltage ..................... Provided by EFD
Nominal Current ................ Included in EFD Current
2.2.3 I/O Specifications
Magnetometer ................... Proprietary Digital
2.2.4 Certification Specifications
The RSM is certified as a component of the EFD1000 E5 system
Software:
NONE
Complex Electronic Hardware (CEH):
NONE
Environmental:
RTCA DO-160E ................. See Environmental Qualification Form Section 13
