EFD1000 E5 Dual Electronic Flight Instrument (EFI) Install Manual
DOCUMENT # 900-00041-001 PAGE 63-226 REVISION D
© Copyright 2019 Aspen Avionics Inc.
Figure 6-11: RSM-External Mounting Locations (Top/Side View) – all aircraft types
12"
Preferred Area
Hat Rack
Baggage
Compartment
NO ZONE
NO ZONE
Less Preferred Locations
(See Note)
12" minimum
separation
39"
NO ZONE
12" minimum
separation
NO ZONE
NO ZONE
NO ZONE
Preferred Area
Less
Preferred Area
(See Note)
NO ZONE
