EFD1000 E5 Dual Electronic Flight Instrument (EFI) Install Manual
DOCUMENT # 900-00041-001 PAGE 37-226 REVISION D
© Copyright 2019 Aspen Avionics Inc.
Figure 4-1A: EFD1000 E5 Authorized VFR with Backups Configuration
E5
RSM
ACU
optional
CM
Required Instruments (existing)
IAS(1)
ALT(1)
Compass(1)
Requires:
-existing Altimeter(1)
-existing Airspeed indicator(1)
-Magnetic Direction Indicator (compass)(1)
(1) –These existing instruments must not be removed or relocated.
VFR with Standby Instruments
GPS
optional
EA100
optional
To Next Page
