6. Device installation and start-up
page 27 / 96 Issue date 18.05.2021, rev. 1.0
Option Explanation
Manual mode – automatically
After therapy selection, the unit is set in manual mode of the operation.
Program mode – automatically
After therapy selection, the unit is set in program mode of the operation.
Mode selection pop-up
After therapy selection, the unit displays a window with a list of operation
mode selection options.
In order to set the appropriate option, select or clear the selection field by its pressing.
6.3.4.2 Program groups / medical fields
This function allows the user to set filters of available program mode options according to the preferred program
groups or medical fields. In order to set the appropriate option, select or clear the selection field by its pressing.
For program groups, the following options are available:
• Preset programs
• Preset sequences
• User programs
• User sequences
• I/t curve – only for electrotherapy, channel A
For medical fields, instead of the preset treatment programs and sequences the following options classified by
medical nomenclature are available:
• Orthopedics
• Sports medicine
• Aesthetic medicine
• Rheumatology
• Neurology
• Urology
• Dermatology
• Angiology
The classification of preset treatment programs and sequences into the above-mentioned categories do not limit
their applications in other fields, according to the knowledge and experience of doctors and physiotherapists.
6.3.4.3 The battery save mode
When the mode is activated, the device switches automatically into the standby mode after two hours of
inactivity, which prolongs the battery life.
6.3.5 Control functions
6.3.5.1 Miscellaneous
In this section there is a possibility to manage some basic service functions:
• Delete user programs – button allows you to remove user-defined programs.
• Calibrate the touch panel – button starts the display calibration procedure. Follow the messages on the
screen. First, touch three points, then validate the operation by touching five points on the screen.
You can also calibrate the display by pressing the key combination simultaneously when starting
the device. The progress bar will change to green and the calibration screen will be displayed when started.
• Test the touch panel – button allows you to check the touch screen operation – on the touched spots an
indicator occurs:
red at the pressed spot,
yellow at the pressure detection spots,
white at the spot where the pen or finger is removed (it should coincide with the red one).
Press the START/STOP key to exit the test mode.
