11. Specification and accessories
page 89 / 96 Issue date 18.05.2021, rev. 1.0
EMC parameters
In compliance with IEC 60601-1-2:2014
Guidance and manufacturer’s declaration – electromagnetic emissions
Emission test
Compliance
RF emissions
CISPR 11
Group 1
RF emissions
CISPR 11
Class B
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations / Flicker emissions
IEC 61000-3-3
Complies
Guidance and manufacturer’s declaration – electromagnetic immunity
Immunity test
IEC60601 test level
Compliance level
Electrostatic discharge (ESD)
IEC 61000-4-2
±8 kV contact
±2, ±4, ±8, ±15 kV air
±8 kV contact
±2, ±4, ±8, ±15 kV air
Recommendation: Floor should be made of wood, concrete or ceramic tile. If floors are covered with synthetic material, the relative
humidity should be at least 30%.
Immunity test IEC60601 test level Compliance level
Radiated RF
IEC 61000-4-3
10 V/m
80MHz do 2,7 GHz
10 V/m
Field strengths from fixed transmitters, such base stations for radio (cellular / cordless) telephones and land mobile radios, amateur
radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the
location in which the PhysioGo.Lite Electro unit is used exceeds the applicable RF compliance level above, the unit should be observed
to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or
relocating the PhysioGo.Lite Electro unit.
Applied compliance level is suitable for home healthcare environment. It means the device may be connected to the public low-voltage
power supply network.
Immunity test IEC60601 test level Compliance level
Electric fast transient / burst
IEC 61000-4-4
±2 kV ±2 kV
Immunity test IEC60601 test level Compliance level
Surges
IEC 61000-4-5
±1 kV line-to-line ±1 kV line-to-line
Immunity test IEC60601 test level Compliance level
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
3 Vrms
150 kHz to 80 MHz
6 Vrms in ISM and amateur radio bands
between 150 kHz – 80 MHz
6 Vrms in ISM and amateur radio bands
between 150 kHz – 80 MHz
Field strengths from fixed transmitters, such base stations for radio (cellular / cordless) telephones and land mobile radios, amateur
radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic
environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the
location in which the PhysioGo.Lite Electro unit is used exceeds the applicable RF compliance level above, the unit should be observed
to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or
relocating the PhysioGo.Lite Electro unit.
Applied compliance level is suitable for home healthcare environment. It means the device may be connected to the public low-voltage
power supply network.
