8. Definitions and parameters
page 61 / 96 Issue date 18.05.2021, rev. 1.0
Symbol Description
Symbol on
the treatment
screen
Available parameters
Polarization
NOR
For such polarization setting red plug is a
positive electrode, and black plug is a
negative electrode.
REV
For such polarization setting red plug is a
negative electrode and black plug is a
positive electrode. Warning means that such
a setting is the reverse of commonly
accepted way of marking polarity.
ALT
Automatic polarization switch in the half
performed treatment.
Amplifier
operation
mode
-
CC – stabilized output current
CV – stabilized output voltage
Maximum
amplitude
-
0,3 – 140 mA in CC mode
Regulation step:
• 0,1 mA in the range of 0,3-10 mA
• 0,5 mA in the range of 10-140 mA
1,5 – 100 V in CV mode, max. 80 mA
Regulation step:
• 0,5 V in the range of 1,5-100 V
Remark: see Table 8.1.
Due to the limitations arising from IEC 60601-2-10, the value of the maximum amplitude depends on the pulse
duration. Permissible values are presented in the table.
Table 8.1. Permitted amplitude values in relation to pulse duration
Pulse duration [ms]
Maximum amplitude [mA]
≤ 30
140
40
120
50
110
60
100
70
90
80
85
≥ 90
80
Triangular pulse currents
Triangular pulse current consists of a sequence of saw-shaped pulses and independently adjusted times of pulse
and pause. It is used to stimulate denervated muscles (struck by flaccid paralysis) and smooth muscles. It is also
applied in electrodiagnostics to determine the I/t curve.
Parameters description:
Symbol Description
Symbol on
the treatment
screen
Available parameters
Treatment time - 1 – 60 minutes, 1 minute step
Shape of the
current
ASYM
Asymmetric triangular pulse current
(unipolar)
