Astar PhysioGo.Lite Electro - Rectangular Pulse Currents

8. Definitions and parameters
page 59 / 96 Issue date 18.05.2021, rev. 1.0
Symbol Description
Symbol on
the treatment
screen
Available parameters
REV
For such polarization setting red plug is a
negative electrode and black plug is a
positive electrode. Warning means that such
a setting is the reverse of commonly
accepted way of marking polarity.
ALT
Automatic polarization switch in the half
performed treatment.
Amplifier
operation
mode
-
CC – stabilized output current
CV – stabilized output voltage
Maximum
amplitude
0,3 – 140 mA in CC mode
Regulation step:
• 0,1 mA in the range of 0,3-10 mA
• 0,5 mA in the range of 10-140 mA
1,5 – 100 V in CV mode, max. 80 mA
Regulation step:
•
0,5 V in the range of 1,5-100 V
Rectangular pulse currents
Rectangular pulse current consists of pulse sequence of rectangular shape and independently adjusted times
of pulse and pause. It may consist of a series of pulses with amplitude modulation, where the intensity of
consecutive pulses in the series gradually increases and decreases (training program). As a result,
electrostimulation parameters can be individually adjusted, depending on the patient's condition and the
purpose of the treatment.
This current is used to stimulate properly innervated muscles. It is also applied in electrodiagnostics to determine
the I/t curve.
Parameters description:
Symbol Description
Symbol on
the treatment
screen
Available parameters
Treatment time - 1 – 60 minutes, 1 minute step
Shape of the
current
- Rectangular pulse current
Continuous or
interrupted
shape of the
current
c_shape
Continuous
• Pulse frequency is 4 kHz
• Duty factor 80%
• Pulse time values of 100 µs and 200 µs
do not have pause
• Pulse frequency is 8 kHz
• Duty factor 90%
• Pulse time values of 100 µs and 200 µs
do not have pause
Pulse duration t_imp
• Regulation in the range of 100 µs – 1 s (variable step)
• Regulation in the range of 100 µs – 200 ms for the
operation of training program PT (variable step)
