7. Unit operation
page 43 / 96 Issue date 18.05.2021, rev. 1.0
It may happen that the muscle reaction is not observed for triangular pulses of 1 s pulse duration. Then you
should interrupt the procedure and start it again from 500 ms pulse duration. For the time value of 1 s should be
set 0 mA value. In this case, parameters are determined on the base of signal amplitude for 300 ms and 200 ms
pulse duration.
There is a possibility to view the saved results of I/t curves. In order to open the list of saved I/t curves press
. Then select the item to be loaded by pressing its name.
You can also delete the saved results of I/t curves. In order to delete the entry, press . Then select the entry
to delete it by pressing its name and confirm the deletion by pressing the button .
Safe shutdown procedure
The work flow for the safe termination of the operation:
Step Description
1.
Click the UNIT ON / OFF (STANDBY) key on the front panel .
2.
After clicking the button, a message will appear on the display as it is shown on the screen below.
3.
If you want to confirm the operation, select the
button, pressing of which will switch the unit
off properly. If you quit turning the unit off, select .
4.
After closing the system, you can disconnect the unit from the power supply network by means of
power switch. If you want to charge the battery, leave the device connected to the mains.
