Maintenance - Maintenance schedule
4812160101_A.pdf 2014-07-04
Every 250 / 750 / 1250 / 1750 hours of operation
Refer to the contents to find the page number of the
sections referred to !
Pos. in fig Action CommentPos. in fig Action Comment
23,22 Check the oil level in rear axle/planetary gears23,22 Check the oil level in rear axle/planetary gears
12 Check the oil level in the drum12 Check the oil level in the drum
13 Check the oil level in drum gearbox13 Check the oil level in drum gearbox
32,31 Clean the coolers32,31 Clean the coolers
16 Check rubber elements and bolted joints16 Check rubber elements and bolted joints
15 Check batteries15 Check batteries
34 Check the AC Optional34 Check the AC Optional
Every 500 / 1500 hours of operation
Refer to the contents to find the page number of the
sections referred to !
Pos. in fig Action CommentPos. in fig Action Comment
4 Inspect the filter element in the air cleaner Replace as required4 Inspect the filter element in the air cleaner Replace as required
23,22 Check the oil level in rear axle/planetary gears23,22 Check the oil level in rear axle/planetary gears
12 Check the oil level in the drum.12 Check the oil level in the drum.
12 Change the oil in the drum gearbox12 Change the oil in the drum gearbox
13 Check the oil level in drum gearbox13 Check the oil level in drum gearbox
32,31 Clean the coolers32,31 Clean the coolers
3 Replace the fuel filter Refer to the engine manual3 Replace the fuel filter Refer to the engine manual
3 Replace the fuel pre-filter Refer to the engine manual3 Replace the fuel pre-filter Refer to the engine manual
5 Lubricate controls and joints5 Lubricate controls and joints
2,25 Change the engine oil and oil filter. * Refer to the engine manual
*) 500h or once every 6
months/once a year
(Cummins/Deutz).
2,25 Change the engine oil and oil filter. * Refer to the engine manual
*) 500h or once every 6
months/once a year
(Cummins/Deutz).
27,28 Lubricate seat bearing/steering chain Optional27,28 Lubricate seat bearing/steering chain Optional
Check the engine's valve clearance (after the first
500 h)
Refer to the engine manualCheck the engine's valve clearance (after the first
500 h)
Refer to the engine manual
98
