Maintenance, 10h
4812160101_A.pdf2014-07-04
Diesel engine Check oil level
Fig. Engine compartment
1. Dipstick
1
Take care not to touch any hot parts of the engine
or the radiator when removing the dipstick. Risk
for burns.
Take care not to touch any hot parts of the engine
or the radiator when removing the dipstick. Risk
for burns.
The dipstick is located beside the engine's oil and fuel
filter.
Pull up the dipstick (1) and check that the oil level is
between the upper and lower marks. For further
details, refer to the engine's instruction manual.
Fuel tank - Filling
Fig. Fuel tank
1. Filler pipe
1
Top up the fuel tank every day. Follow the engine
manufacturer's specifications for diesel fuel.
The new Tier 4i/Stage IIIB Cummins engines
require the use of Ultra Low Sulphur Diesel
(ULSD) fuel, which has a sulphur content of 15
ppm (parts per million) or less. A higher sulphur
content will cause operating problems and put the
useful life of components at risk, which can lead
to engine trouble.
The new Tier 4i/Stage IIIB Cummins engines
require the use of Ultra Low Sulphur Diesel
(ULSD) fuel, which has a sulphur content of 15
ppm (parts per million) or less. A higher sulphur
content will cause operating problems and put the
useful life of components at risk, which can lead
to engine trouble.
Stop the engine. Short-circuit (press) the filler gun
against a non-insulated part of the roller before
refuelling, and against the filler pipe (1) while
refuelling.
Stop the engine. Short-circuit (press) the filler gun
against a non-insulated part of the roller before
refuelling, and against the filler pipe (1) while
refuelling.
Never refuel while the engine is running. Do not
smoke and avoid spilling fuel.
Never refuel while the engine is running. Do not
smoke and avoid spilling fuel.
The tank holds 260 liters of fuel.
105
