Atlas Copco CA3500DCO User Manual

Technical specifications
4812160101_A.pdf2014-07-04
Dimensions, top view
Dimensions mm inDimensions mm in
B Width, standard equipped rollerB Width, standard equipped roller
CA3500, CA3600 2304 91CA3500, CA3600 2304 91
CA5000, CA6000 2340 92CA5000, CA6000 2340 92
O1 Overhang, left frame sideO1 Overhang, left frame side
CA3500, CA3600 87 3.4CA3500, CA3600 87 3.4
CA5000, CA6000 105 4.1CA5000, CA6000 105 4.1
O2 Overhang, right frame sideO2 Overhang, right frame side
CA3500, CA3600 87 3.4CA3500, CA3600 87 3.4
CA5000, CA6000 105 4.1CA5000, CA6000 105 4.1
R1 Turn radius, externalR1 Turn radius, external
CA3500, CA3600 5600 220CA3500, CA3600 5600 220
CA5000, CA6000 5800 228CA5000, CA6000 5800 228
R2 Turning radius, innerR2 Turning radius, inner
CA3500, CA3600 3210 126CA3500, CA3600 3210 126
CA5000, CA6000 3330 131CA5000, CA6000 3330 131
W1 Width, tractor section 2130 84W1 Width, tractor section 2130 84
W2 Width, drum 2130 84W2 Width, drum 2130 84
