Technical specifications
4812160101_A.pdf 2014-07-04
Dimensions, side view
Dimensions mm inDimensions mm in
A Wheelbase, drum and wheelA Wheelbase, drum and wheel
CA3500, CA3600 2990 118CA3500, CA3600 2990 118
CA5000, CA6000 3100 122CA5000, CA6000 3100 122
L Length, standard equipped rollerL Length, standard equipped roller
CA3500, CA3600 6000 236CA3500, CA3600 6000 236
CA5000, CA6000 6240 246CA5000, CA6000 6240 246
H1 Height, with ROPS/cabH1 Height, with ROPS/cab
CA3500, CA3600 2870 113CA3500, CA3600 2870 113
CA5000, CA6000 2890 114CA5000, CA6000 2890 114
H2 Height, without ROPSH2 Height, without ROPS
CA3500, CA3600 2267 89CA3500, CA3600 2267 89
CA5000, CA6000 2267 89CA5000, CA6000 2267 89
D Diameter, drum (D)D Diameter, drum (D)
CA3500, CA3600 1518 60CA3500, CA3600 1518 60
CA5000 1536 60.5CA5000 1536 60.5
CA6000 1546 60.9CA6000 1546 60.9
S Thickness, drum amplitude, Nominal (D)S Thickness, drum amplitude, Nominal (D)
CA3500, CA3600 34 1.3CA3500, CA3600 34 1.3
CA5000 43 1.7CA5000 43 1.7
CA6000 48 1.9CA6000 48 1.9
P N/AP N/A
K1 Clearance, tractor frame 450 18K1 Clearance, tractor frame 450 18
K2 Clearance, drum frameK2 Clearance, drum frame
CA3500, CA3600 442 17.5CA3500, CA3600 442 17.5
CA5000, CA6000 450 18CA5000, CA6000 450 18
