Atlas Copco CA3500DCO User Manual

Machine description
4812160101_A.pdf 2014-07-04
Fuse box at master switch (Deutz)
Fig. Fuse box, battery disconnector
switch
1
3
2
4
The figure shows the position of the fuses.
The amperage and function of the fuses are shown
below. All fuses are flat pin fuses.
1. Main fuse 50A1. Main fuse 50A
2. Cab 30A2. Cab 30A
3.
*
Diesel engine ECU 30A3.
*
Diesel engine ECU 30A
3.
**
Burner, air pump 60A3.
**
Burner, air pump 60A
4.
*
Grid heater 40A4.
*
Grid heater 40A
4.
**
Burner, heater plug 25A4.
**
Burner, heater plug 25A
*
(IIIA/T3)
*
(IIIA/T3)
**
(IIIB/T4i)
**
(IIIB/T4i)
56
