Operation
4812160101_A.pdf 2014-07-04
Switching off
3
2
1
Fig. Control panel
1. Display
2. Ignition lock
3. Parking brake
Set the speed control in idling position and allow the
engine to idle for a few minutes to cool down.
Check the display to see if any faults are indicated.
Switch off all lights and other electrical functions.
Activate the parking brake (3) and then turn the
ignition lock (2) to the left to the off position.
Fit the instrument cover on the display and top of the
control box (on rollers without cab), and lock it.
Parking
Chocking the drums
Fig. Positioning
1. Chocks
1
Never disembark from the machine when the is
engine running, unless the parking brake is
activated.
Never disembark from the machine when the is
engine running, unless the parking brake is
activated.
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drums
if the roller is parked on sloping ground.
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drums
if the roller is parked on sloping ground.
Remember the risk of freezing during the winter.
Fill the engine cooling system and the
screenwash bottle in the cab with suitable
anti-freeze mixtures. See also the maintenance
instructions.
Remember the risk of freezing during the winter.
Fill the engine cooling system and the
screenwash bottle in the cab with suitable
anti-freeze mixtures. See also the maintenance
instructions.
72
