Atlas Copco CA3500DCO User Manual

Operation
4812160101_A.pdf2014-07-04
Parking brake
1
Fig. Control panel
1. Parking brake
Ensure that the parking brake (1) is definitely
switched on.
Ensure that the parking brake (1) is definitely
switched on.
Brake is always activated in Neutral position.
(automatic 1.5 sec.)
The parking brake must be activated to start the
machine!
Display - Control
1
2
Fig. Control panel
1. Ignition key
2. Status screen
Sit down for all operations.
Turn the ignition key (1) to position I, the start screen
will be shown in display.
4
5
3
Fig. Status image
3. Fuel level
4. Hourmeter
5. Voltmeter
Check that the voltmeter (5) reads at least 24 volts,
and that the fuel gauge (3) show a reading.
The hourmeter (4) registers and shows the total
number of hours the engine has run.
59
