Technical specifications
4812160101_A.pdf2014-07-04
Amplitude mode mm (in)Amplitude mode mm (in)
1 0,2 (0.008)1 0,2 (0.008)
2 0,4 (0.016)2 0,4 (0.016)
3 0,6 (0.024) 3 0,6 (0.024)
4 0,8 (0.032)4 0,8 (0.032)
5 1,0 (0.039) 5 1,0 (0.039)
6 1,2 (0.047)6 1,2 (0.047)
7 1,4 (0.055)7 1,4 (0.055)
8 1,6 (0.063)8 1,6 (0.063)
9 1,8 (0.071)9 1,8 (0.071)
10 2,0 (0.079)10 2,0 (0.079)
The amplitude indicator shows the percentage (%) of
maximum amplitude.
Vibration frequencyVibration frequency
CA3500, CA3600 28 (Hz)CA3500, CA3600 28 (Hz)
1680 (vpm)1680 (vpm)
CA5000 27 (Hz)CA5000 27 (Hz)
1620 (vpm)1620 (vpm)
CA6000 27 (Hz)CA6000 27 (Hz)
1620 (vpm)1620 (vpm)
Centrifugal forceCentrifugal force
CA3500, CA3600 161 (kN)CA3500, CA3600 161 (kN)
36 225 (lb)36 225 (lb)
CA5000 280 (kN)CA5000 280 (kN)
63 000 (lb)63 000 (lb)
CA6000 300 (kN)CA6000 300 (kN)
67 500 (lb)67 500 (lb)
19
