143
2467S–AVR–07/09
ATmega128
Note that a forced outpu
t compare (FOC1C) strobe
will not set the OCF1C flag.
OCF1C is automatically cleared when the Output Compare Match 1 C interrupt vector is exe-
cuted. Alternatively, OCF1C can be cleared by writing
a logic one to its bit location.
