Atmel ATmega128

338
2467S–AVR–07/09
ATmega128
Figure 170. Idle Supply Current vs. V
CC
(Internal RC Oscillator, 1 MHz)
Figure 171. Idle Supply Current vs. V
CC
(Internal RC Oscillator, 2 MHz)
IDLE SUPPLY CURRENT vs. V
CC
INTERNAL RC OSCILLATOR, 1 MHz
85 °C
25 °C
-40 °C
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
IDLE SUPPLY CURRENT vs. V
CC
INTERNAL RC OSCILLATOR, 2 MHz
85 °C
25 °C
-40 °C
0
0.5
1
1.5
2
2.5
3
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
