59
2467S–AVR–07/09
ATmega128
1.
In the same oper
ation, write a log
ical one to WDCE and
WDE. Eve
n though the WDE
alwa
ys is set, the WDE must be written to one to start the timed sequence.
2.
Within the ne
xt f
our cloc
k cycles,
in the same operation, write the WDP bits as desired,
but
with the WDCE bit cleared. The v
alue written to the WDE bit is irrele
vant.
