Atmel ATmega32M1 User Manual

145
7647H–AVR–03/12
Atmel ATmega16/32/64/M1/C1
14.8.1 Input Description
Table 14-1. Internal Inputs
Table 14-2. Block Inputs
14.8.2 Output Description
Table 14-3. Block Outputs
Table 14-4. Internal Outputs
Note: 1. See “Analog Synchronization” on page 149.
Name Description
Type
Width
POCR_RB[11:0]
Compare Value which Reset Signal on Part B
(PSCOUTnB)
Register
12 bits
POCRnSB[11:0] Compare Value which Set Signal on Part B (PSCOUTnB)
Register
12 bits
POCRnRA[11:0]
Compare Value which Reset Signal on Part A
(PSCOUTnA)
Register
12 bits
POCRnSA[11:0] Compare Value which Set Signal on Part A (PSCOUTnA)
Register
12 bits
CLK I/O Clock Input from I/O clock Signal
CLK PLL Clock Input from PLL Signal
AC0O Analog Comparator 0 Output Signal
AC1O Analog Comparator 1 Output Signal
AC2O Analog Comparator 2 Output Signal
Name Description
Type
Width
PSCIN0 Input 0 used for Fault function Signal
PSCIN1 Input 1 used for Fault function Signal
PSCIN2 Input 2 used for Fault function Signal
Name Description
Type
Width
PSCOUT0A PSC Module 0 Output A Signal
PSCOUT0B PSC Module 0 Output B Signal
PSCOUT1A PSC Module 1 Output A Signal
PSCOUT1B PSC Module 1 Output B Signal
PSCOUT2A PSC Module 2 Output A Signal
PSCOUT2B PSC Module 2 Output B Signal
Name Description
Type
Width
IRQPSCn PSC Interrupt Request : two souces, overflow, fault Signal
PSCASY ADC Synchronization (+ Amplifier Syncho. )
(1)
Signal
