347
7647H–AVR–03/12
Atmel ATmega16/32/64/M1/C1
29. Register Summary
Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page
(0xFF) Reserved – – – – – – – –
(0xFE) Reserved – – – – – – – –
(0xFD) Reserved – – – – – – – –
(0xFC) Reserved – – – – – – – –
(0xFB) Reserved – – – – – – – –
(0xFA) CANMSG MSG 7 MSG 6 MSG 5 MSG 4 MSG 3 MSG 2 MSG 1 MSG 0 page 201
(0xF9) CANSTMPH TIMSTM15 TIMSTM14 TIMSTM13 TIMSTM12 TIMSTM11 TIMSTM10 TIMSTM9 TIMSTM8 page 201
(0xF8) CANSTMPL TIMSTM7 TIMSTM6 TIMSTM5 TIMSTM4 TIMSTM3 TIMSTM2 TIMSTM1 TIMSTM0 page 201
(0xF7) CANIDM1
IDMSK
28
IDMSK
27
IDMSK
26
IDMSK
25
IDMSK
24
IDMSK
23
IDMSK
22
IDMSK
21 page 200
(0xF6) CANIDM2
IDMSK
20
IDMSK
19
IDMSK
18
IDMSK
17
IDMSK
16
IDMSK
15
IDMSK
14
IDMSK
13 page 200
(0xF5) CANIDM3
IDMSK
12
IDMSK
11
IDMSK
10
IDMSK
9
IDMSK
8
IDMSK
7
IDMSK
6
IDMSK
5 page 200
(0xF4) CANIDM4
IDMSK
4
IDMSK
3
IDMSK
2
IDMSK
1
IDMSK
0RTRMSK –IDEMSK page 200
(0xF3) CANIDT1
IDT
28
IDT
27
IDT
26
IDT
25
IDT
24
IDT
23
IDT
22
IDT
21 page 198
(0xF2) CANIDT2
IDT
20
IDT
19
IDT
18
IDT
17
IDT
16
IDT
15
IDT
14
IDT
13 page 198
(0xF1) CANIDT3
IDT
12
IDT
11
IDT
10
IDT
9
IDT
8
IDT
7
IDT
6
IDT
5 page 198
(0xF0) CANIDT4
IDT
4
IDT
3
IDT
2
IDT
1
IDT
0 RT RTAG R B1 TAG R B0 TAG page 198
(0xEF) CANCDMOB CONMOB1 CONMOB0 RPLV IDE DLC3 DLC2 DLC1 DLC0 page 197
(0xEE) CANSTMOB DLCW TXOK RXOK BERR SERR CERR FERR AERR page 196
(0xED) CANPAGE MOBNB3 MOBNB2 MOBNB1 MOBNB0 AINC INDX2 INDX1 INDX0 page 196
(0xEC) CANHPMOB HPMOB3 HPMOB2 HPMOB1 HPMOB0 CGP3 CGP2 CGP1 CGP0 page 195
(0xEB) CANREC REC7 REC6 REC5 REC4 REC3 REC2 REC1 REC0 page 195
(0xEA) CANTEC TEC7 TEC6 TEC5 TEC4 TEC3 TEC2 TEC1 TEC0 page 195
(0xE9) CANTTCH TIMTTC15 TIMTTC14 TIMTTC13 TIMTTC12 TIMTTC11 TIMTTC10 TIMTTC9 TIMTTC8 page 195
(0xE8) CANTTCL TIMTTC7 TIMTTC6 TIMTTC5 TIMTTC4 TIMTTC3 TIMTTC2 TIMTTC1 TIMTTC0 page 195
(0xE7) CANTIMH CANTIM15 CANTIM14 CANTIM13 CANTIM12 CANTIM11 CANTIM10 CANTIM9 CANTIM8 page 195
(0xE6) CANTIML CANTIM7 CANTIM6 CANTIM5 CANTIM4 CANTIM3 CANTIM2 CANTIM1 CANTIM0 page 195
(0xE5) CANTCON TPRSC7 TPRSC6 TPRSC5 TPRSC4 TPRSC3 TPRSC2 TRPSC1 TPRSC0 page 194
(0xE4) CANBT3 – PHS22 PHS21 PHS20 PHS12 PHS11 PHS10 SMP page 194
(0xE3) CANBT2 – SJW1 SJW0 – PRS2 PRS1 PRS0 – page 193
(0xE2) CANBT1 – BRP5 BRP4 BRP3 BRP2 BRP1 BRP0 – page 192
(0xE1) CANSIT1 – – – – – – – – page 192
(0xE0) CANSIT2 – – SIT5 SIT4 SIT3 SIT2 SIT1 SIT0 page 192
(0xDF) CANIE1 – – – – – – – – page 192
(0xDE) CANIE2 – – IEMOB5 IEMOB4 IEMOB3 IEMOB2 IEMOB1 IEMOB0 page 192
(0xDD) CANEN1 – – – – – – – – page 191
(0xDC) CANEN2 – – ENMOB5 ENMOB4 ENMOB3 ENMOB2 ENMOB1 ENMOB0 page 191
(0xDB) CANGIE ENIT ENBOFF ENRX ENTX ENERR ENBX ENERG ENOVRT page 190
(0xDA) CANGIT CANIT BOFFIT OVRTIM BXOK SERG CERG FERG AERG page 189
(0xD9) CANGSTA
–OVRG – TXBSY RXBSY ENFG BOFF ERRP page 188
(0xD8) CANGCON ABRQ OVRQ TTC SYNTTC LISTEN TEST ENA/STB
SWRES page 187
(0xD7) Reserved – – – – – – – –
(0xD6) Reserved – – – – – – – –
(0xD5) Reserved – – – – – – – –
(0xD4) Reserved – – – – – – – –
(0xD3) Reserved – – – – – – – –
(0xD2) LINDAT LDATA7 LDATA6 LDATA5 LDATA4 LDATA3 LDATA2 LDATA1 LDATA0 page 229
(0xD1) LINSEL
– – – – /LAINC LINDX2 LINDX1 LINDX0 page 229
(0xD0) LINIDR LP1 LP0 LID5 / LDL1 LID4 / LDL0 LID3 LID2 LID1 LID0 page 228
(0xCF) LINDLR LTXDL3 LTXDL2 LTXDL1 LTXDL0 LRXDL3 LRXDL2 LRXDL1 LRXDL0 page 228
(0xCE) LINBRRH
– – – – LDIV11 LDIV10 LDIV9 LDIV8 page 227
(0xCD) LINBRRL LDIV7 LDIV6 LDIV5 LDIV4 LDIV3 LDIV2 LDIV1 LDIV0 page 227
(0xCC) LINBTR LDISR – LBT5 LBT4 LBT3 LBT2 LBT1 LBT0 page 227
(0xCB) LINERR LABORT LTOERR LOVERR LFERR LSERR LPERR LCERR LBERR page 226
(0xCA) LINENIR
– – – – LENERR LENIDOK LENTXOK LENRXOK page 225
(0xC9) LINSIR LIDST2 LIDST1 LIDST0 LBUSY LERR LIDOK LTXOK LRXOK page 224
(0xC8) LINCR LSWRES LIN13 LCONF1 LCONF0 LENA LCMD2 LCMD1 LCMD0 page 223
(0xC7) Reserved – – – – – – – –
(0xC6) Reserved – – – – – – – –
(0xC5) Reserved – – – – – – – –
(0xC4) Reserved – – – – – – – –
(0xC3) Reserved – – – – – – – –
(0xC2) Reserved – – – – – – – –
(0xC1) Reserved – – – – – – – –
(0xC0) Reserved – – – – – – – –
(0xBF) Reserved – – – – – – – –
