201
7647H–AVR–03/12
Atmel ATmega16/32/64/M1/C1
• Bit 2 – RTRMSK: Remote Transmission Request Mask
– 0 - comparison true forced
– 1 - bit comparison enabled.
• Bit 1 – Reserved Bit
Writing zero in this bit is recommended.
• Bit 0 – IDEMSK: Identifier Extension Mask
– 0 - comparison true forced
– 1 - bit comparison enabled.
16.11.5 CAN Time Stamp Registers - CANSTML and CANSTMH
• Bits 15:0 - TIMSTM15:0: Time Stamp Count
CAN time stamp counter range 0 to 65,535.
16.11.6 CAN Data Message Register - CANMSG
• Bit 7:0 – MSG7:0: Message Data
This register contains the CAN data byte pointed at the page MOb register.
After writing in the page MOb register, this byte is equal to the specified message location of the
pre-defined identifier + index. If auto-incrementation is used, at the end of the data register writ-
ing or reading cycle, the index is auto-incremented.
The range of the counting is 8 with no end of loop (0, 1,..., 7, 0,...).
Bit 76543210
TIMSTM7 TIMSTM6 TIMSTM5 TIMSTM4 TIMSTM3 TIMSTM2 TIMSTM1 TIMSTM0 CANSTML
TIMSTM15 TIMSTM14 TIMSTM13 TIMSTM12 TIMSTM11 TIMSTM10 TIMSTM9 TIMSTM8 CANSTMH
Bit 151413121110 9 8
Read/Write R R R R RRRR
Initial Value--------
Bit 76543210
MSG 7 MSG 6 MSG 5 MSG 4 MSG 3 MSG 2 MSG 1 MSG 0 CANMSG
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Initial Value--------
