Atmel ATmega16/32/64/M1/C1
Table 14-12. Input Mode Operation
14.16.10 PSC Interrupt Mask Register – PIM
• Bit 7:4 – not use
not use.
• Bit 3 – PEVE2 : PSC External Event 2 Interrupt Enable
When this bit is set, an external event which can generates a a fault on module 2 generates also
an interrupt.
• Bit 2 – PEVE1 : PSC External Event 1 Interrupt Enable
When this bit is set, an external event which can generates a fault on module 1 generates also
an interrupt.
• Bit 1 – PEVE0 : PSC External Event 0 Interrupt Enable
When this bit is set, an external event which can generates a fault on module 0 generates also
an interrupt.
• Bit 0 – PEOPE : PSC End Of Cycle Interrupt Enable
When this bit is set, an interrupt is generated when PSC reaches the end of the whole cycle.
PRFMn2:0 Description
000b No action, PSC Input is ignored
001b Disactivate module n Outputs A
010b Disactivate module n Output B
011b Disactivate module n Output A & B
10x Disactivate all PSC Output
11xb Halt PSC and Wait for Software Action
Bit 76543210
- - - - PEVE2 PEVE1 PEVE0 PEOPE PIM
Read/Write R R R R R/W R/W R/W R/W
Initial Value 00000000
