Note: 1. “Max” means the highest value where the pin is guaranteed to be read as low
2. “Min” means the lowest value where the pin is guaranteed to be read as high
3. Although each I/O port can sink more than the test conditions (10mA at V
CC
= 5V, 6mA at V
CC
= 3V) under steady state con-
ditions (non-transient), the following must be observed:
1] The sum of all IOL, for ports B0 - B1, C2 - C3, D4, E1 - E2 should not exceed 70mA.
2] The sum of all IOL, for ports B6 - B7, C0 - C1, D0 -D3, E0 should not exceed 70mA.
3] The sum of all IOL, for ports B2 - B5, C4 - C7, D5 - D7 should not exceed 70mA.
If IOL exceeds the test condition, VOL may exceed the related specification. Pins are not guaranteed to sink current greater
than the listed test condition.
V
OH3
Output High Voltage
(4)
(RESET pin as I/O)
I
OH
= –0.6mA, V
CC
= 5V
I
OH
= –0.2mA, V
CC
= 3V
3.8
1.8
V
V
I
IL
Input Leakage
Current I/O Pin
V
CC
= 5.5V, pin low
(absolute value), except Port E
50 nA
I
IH
Input Leakage
Current I/O Pin
V
CC
= 5.5V, pin high
(absolute value), except Port E
50 nA
R
RST
Reset Pull-up Resistor 30 200 kΩ
R
pu
I/O Pin Pull-up Resistor 20 50 kΩ
I
CC
Power Supply Current
Active 8MHz, V
CC
= 3V, RC
osc, PRR = 0xFF
3.8 8 mA
Active 16MHz, V
CC
= 5V, Ext
Clock, PRR = 0xFF
14 30 mA
Idle (16K and 32K devices)
V
CC
= 3V, F = 8MHz
V
CC
= 5V, F = 16MHz
1.1
4.0
8
15
mA
mA
Idle (64K devices only)
V
CC
= 3V, F = 8MHz
V
CC
= 5V, F = 16MHz
1.5
5.8
8
15
mA
mA
Power-down mode
(5)
WDT enabled, V
CC
= 5V
t0 < 85°C
830µA
WDT enabled, V
CC
= 5V
85°C < t0 < 125°C
21 120 µA
WDT disabled, V
CC
= 5V
t0 < 85°C
225µA
WDT disabled, V
CC
= 5V
85°C < t0 < 125°C
16 100 µA
V
hysr
Analog Comparator
Hysteresis Voltage
V
CC
= 5V, V
in
= 3V
Rising Edge
Falling Edge –100
25
–35
70 mV
mV
I
ACLK
Analog Comparator
Input Leakage Current
V
CC
= 5V
V
in
= V
CC
/2
–50 +50 nA
t
ACID
Analog Comparator
Propagation Delay
V
CC
= 2.7V
V
CC
= 5.0V
(6)
(6)
ns
I
SRC
Current Source Value
V
CC
= 5V: Max R
load
30KΩ
V
CC
= 3V: Max R
load
15KΩ
95 100 105 µA
T
A
= -40°C to +125°C, V
CC
= 2.7V to 5.5V (unless otherwise noted) (Continued)
Symbol Parameter Condition Min. Typ. Max. Units
