3.4. MAIN COMPONENTS
7 1145 10
68
13
29
POS. ELEMENT NOTES
1 STRUCTURE
2 CONTROL PANEL
3 DOOR WITH HANDLE
4 SHELF
5 SHELF SUPPORT
6 REMOVABLE CONDENSATE DRIP TRAY
7 EVAPORATOR UNIT
Including:
▪ Fan
▪ Resistor
8 FEET
9 REFRIGERATING UNIT
Including:
▪ Compressor
▪ Condenser
▪ Fan
10 CORE PROBE
11 CHAMBER TEMPERATURE PROBE
