Attila DIGITAL - Use of Touch Version Blast Chiller; Activation; Blasting Modes

ATTILA
EN
40
8.5. USE OF “TOUCH” VERSION BLAST CHILLER
8.5.1. ACTIVATION
Do not start the equipment with wet hands or when there is contact with water.
STEP ACTION PICTURE
1
Press the O/I main switch.
Note: when switched on, the button lights up green.
2
Press and hold the button for 4 seconds to switch on the equipment.
8.5.2. BLASTING MODES
The blasting cycle can be configured using the buttons:
• TARGET - Timed or with core probe
• TEMPERATURE - positive (+3°C) or negative (-18°C)
• MODE - Soft or Hard.
The combination of the above selections produces eight blasting cycles:
TARGET TEMPERATURE METHOD
PARAMETER
VALUE
DISPLAY STRING
Timed
Positive
Hard 0 PMH
Soft 1 PMS
Negative
Hard 4 PAH
Soft 5 PAS
With core probe
Positive
Hard 2 nMH
Soft 3 nMS
Negative
Hard 6 nAS
Soft 7 hLd
