USE AND MAINTENANCE MANUAL
ATTILA
23
EN
7.1.2. CYCLE-DEPENDENT INTERFACE CHARACTERISTICS
The commands on the interface take on characteristics depending on the operating cycle of the equipment.
STOPPING PHASE
DISPLAY VISUALISATION
The display shows the time (in hours and minutes) if a time cycle is selected, or
the temperature of the core probe in °C for a probe cycle.
The dot at the top of the second display indicates the selection of a negative cycle.
CONTROL FEATURES
The , and buttons allow you to select the blasting cycle.
Pressing the button automatically sets a positive or negative probe cycle.
Pressing the button for 4 sec. puts the device in stand-by mode.
Pressing the or button automatically sets a timed cycle if a core probe
cycle was previously selected, or sets the blasting to more or less time.
If the buzzer is active, the first press of the button silences the buzzer.
Pressing the button starts the blasting cycle.
BLASTING PHASE
DISPLAY VISUALISATION
The display shows the remaining time (in hours or minutes) if a time cycle is
selected or the temperature of the core probe in °C for a probe cycle.
If door presence is enabled (P1=1) and the contact is not closed, “dr” appears on
the display to indicate that the door is open.
CONTROL FEATURES
During the “Core probe” and “Time” programmes, pressing displays the
elapsed time from the start of the cycle.
Pressing the button displays the temperature read by the chamber probe.
This display remains for 5 sec.
If the buzzer is active, the first press of the button silences the buzzer.
Pressing starts or ends the blasting/storage cycle.
At the end of the positive blasting phase, there is an automatic switch to storage at a
temperature of 0 to +3°C.
At the end of the negative blasting phase, there is an automatic switch to storage at a
temperature of -22 to -25°C.
