101
1. Connection Mode — there are two connection modes available for selection.
⚫ Bluetooth — when paired to a wireless device, the connection state displays
as “Paired”, otherwise, it displays as “Unpaired.”
⚫ Firmware Upgrade — updates the V200 with the latest version of firmware via
the Internet.
2. Bluetooth Listing
The list section displays the serial numbers for all VCI devices available for pairing.
Tap a VCI device to start pairing. The BT status icon displayed to the left of the
device name indicates the received signal strength.
11.4.1 Bluetooth Connection
The MaxiVCI V200 needs to be connected to the vehicle, so that it is powered during the
synchronization procedure. Turn the vehicle’s ignition to the ON position. Ensure the
tablet has sufficient battery power or is connected to an external power supply.
➢ To pair the MaxiVCI V200 with the tablet
1. Power on the tablet.
2. Insert the 16-pin vehicle data connector of the MaxiVCI V200 to the vehicle data
link connector (DLC).
3. Tap the Settings application button on the MaxiTPMS Job Menu of the tablet,
and select VCI Manager.
4. Tap Scan at the upper-right corner of the tablet’s screen. The device will
automatically search for available pairing units.
5. The device name may display as “Maxi” suffixed with a serial number. Select
the appropriate device for pairing.
6. When paired successfully, the connection status displays the device name with
the message “Paired.”
7. Once paired, the VCI button on the upper-right corner of the screen will display
a green check and the Connection LED on the MaxiVCI V200 illuminates solid
green. This signifies that the tablet is connected to the MaxiVCI V200, and it is
ready to perform vehicle diagnosis.
8. Tap the paired device again to unpair it.
9. Tap the Home icon on the top-left to return to the MaxiTPMS Job Menu.
NOTE
A MaxiVCI V200 can be paired to only one tablet at a time, and once it’s paired, the
device will not be discoverable to other devices.
