Autel MAXITPMS ITS600 - Technical Specifications; Test Preparation; Inspect the Battery; Connect the Battery Tester

56
6.1.3 Technical Specifications
Table 6-2 Technical specifications
Item
Description
Connectivity
⚫ USB 2.0, Type C
⚫ Bluetooth 4.2
Input Voltage
5 V DC
Working Current
< 150 mA at 12 V DC
Internal Battery
3.7 V/800 mAh lithium-ion polymer battery
CCA Range
100 to 2000 A
Voltage Range
6 to 36 V
Working Temp.
–10 °C to 50 °C (14 °F to 122 °F)
Storage Temp.
–20 °C to 60 °C (–4 °F to 140 °F)
Dimension
(L x W x H)
107 mm (4.21’’) x 75 mm (2.95”) x 26 mm (1.02”)
(clamp cable not included)
Weight
320 g (0.7 lb.)
6.2 Test Preparation
6.2.1 Inspect the Battery
Before starting a test, inspect the battery for:
⚫ Cracking, buckling or leaking (If you see any of these defects, replace the battery.)
⚫ Corroded, loose or damaged cables and connections (Repair or replace as needed.)
⚫ Corrosion on the battery terminals, and dirt or acid on the case top (Clean the case
and terminals using a wire brush and a mixture of water and baking soda.)
6.2.2 Connect the Battery Tester
➢ To connect BT506 with the MaxiTPMS tablet
1. Turn on both BT506 and the MaxiTPMS tablet.
2. Tap the Settings application button on the MaxiTPMS Job Menu, and select
VCI Manager.
