If the search period expires and no
sensor is activated or decoded, the
sensor may be mounted incorrectly
or does not function. The table
displays “Failed.”
If the tire pressure is not in the
normal range, the icon will turn red.
If a sensor with a duplicate ID has
been read, the screen displays a
message “Sensor ID duplicated.”
Repeat the test procedure.
4.5 TPMS Diagnostics
The Diagnostics function is used to check the status of the TPMS system. This function
requires connection with the test vehicle.
4.5.1 Diagnosis Operations
Tap Diagnostics, and the tablet will automatically communicate with the vehicle.
Figure 4-11 Communication Screen
