4.9.3 Details
The Details screen shows a wide variety of tire and brake disc information. After
measurements are shown on the Wear detection screen, select a wheel location, tap the
corresponding tire or brake disc icon under the Details column to enter the next screen.
Different check mode varies in terms of displaying sections. Below are the main sections
featured on the Details screen:
1) Graphic measurements — shows the measurements data graphically with various
colors indicating different tire and/or brake disc wear conditions,
⚫ All Tread Check & Single Check — presents only the tire tread wear conditions
graphically while the all tread check mode displays measurements of the inner,
center, and outer areas of the tire, while for the single check mode.
⚫ Quick Check — displays both the tire tread & brake disc wear conditions
graphically.
⚫ Brake Disc Check — displays only the brake disc wear.
2) Braking distance — displays the stopping distance for the test vehicle graphically
with the corresponding tire tread depth. The braking distance varies with the type of
tires changed accordingly. This section also followed by wear analysis and
maintenance suggestions.
⚫ Quick Check — specially contains analysis of brake disc wear.
⚫ Brake Disc Check — braking distance is available for all check modes, except
for Brake disc mode.
The following three tire-related sections are provided in all the check modes except for
the brake disc one:
3) Tire Condition — presents with nine tire status, including normal, worn, and bulge.
4) Tire DOT — scans the tire DOT serial number located on the sidewall to acquire
basic characteristics such as tire age, recall status, and warning. Refer to Tire DOT
for additional information.
5) Tire Specification — presents a series of options regarding tire characteristics,
including Make, Tire Width, and Type Code.
NOTE
On the Details screen, the measurements are shown graphically and changes colors with
the Tire Condition manually selected to provide a more comprehensive analysis.
