easy for technicians.
4.9.2.4 Brake Disc Check
The brake disc check function checks for brake disc wear and provides wear analysis.
Similar to single check that targets tire depth, this check mode focus on brake disc
measurements only.
➢ To pair the tablet with the TBE device via Wi-Fi direct mode
1. On the TBE device, go to Settings > Network connection > Wi-Fi direct, and
swipe the Wi-Fi direct toggle to turn it on.
2. On the tablet, go to Settings > TBE Manager to open the TBE Manager screen.
Or, open the TPMS application, on the Wear Detection screen, tap the TBE icon
to access the TBE Manager screen for connection.
3. Tap Scan at the upper-right corner of the tablet’s screen. The tablet will
automatically search for available TBE devices.
4. The name of the device will appear. Select the device for connection, and tap
the device name to establish a communication link.
5. After the connection is established, open the Tire Tread application on the TBE
device and start measuring.
NOTE
A prompt will display when open the Tire Tread function, notifying the current check mode
and if want to switch to another one. You can also switch between all tread check and
single check in the Check Settings via the TBE device.
6. The measurement data on the TBE device will automatically transfer to and
display on the paired tablet.
7. To switch to brake disc or quick check, take quick check for example, simply
open the Quick Check application on the TBE device to perform measurements.
The Data Query function on the TBE device stores data of the previous measurement
session, which will display on the tablet screen automatically. Once a new measuring
session starts, the previous data will naturally be replaced by the newly tested one.
NOTE
Once paired, tire & brake disc wear condition, DOT, and other tire-related information will
be automatically transferred from TBE device to the paired tablet.
