Autronica AutroGuard Multicriteria Protector V-430 Series User Manual

Mounting Instructions
AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339-4, 2022-12-09,
Autronica Fire and Security AS
Page 57
9.3.2 Wire Routing Arrangement Inside Protector Base
The wires must be supported by the cable holders. Make sure that
the wire routing arrangement shown below is used (the arrows point
to the cable holders).
Cable holder
Cable holder
