Technical Specifications
AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339-4, 2022-12-09,
Autronica Fire and Security AS
Page 21
4. Technical Specifications
4.1 Protector and Base
Height = 45,3mm (49,6mm including base)
Diameter = 113,6mm
127g (172g including base)
PC ABS, flammability classification UL94 V-0
Black: RAL9005 (only V-430)
Customized colours will be available on request (only V-430)
IP44D (IP55 when used with conduit box)
Current consumption base - Average
Current consumption protector - Average
Current consumption – Normal (base +
protector)
Current consumption – alarm indicator
(Red LED indicator ON)
Current consumption – fault indicator
(Yellow LED indicator ON)
Quiescent Current Sounder
160µA (+ 120µA for protector and base)
320µA (+ 120µA for protector and base)
Quiescent Current Sounder + VAD
360µA (+ 120µA for protector and base)
Minimum and maximum rated operating
voltage
10,0V - 26,0V for protector base
18,0V - 26,0V for protector base when add-on boards (VAD/Sounder)
Rated operating voltage (applies to UL
variant)
Average current consumption alarm
1,9mA (the alarm current is the quiescent current + LED indicator
current)
Average current consumption with
external LED
2.16% ± 0.54%/ft obscuration
Heat detector spacing (applies to UL
variant)
V-100 Standard base for protector series V-430
V-110 standard base with SIL2 approval, with remote LED output for
protector series V-530
V-120 EX base with SIL2 approval, without remote LED output for
• V-430/V-530: AutroSafe system version 4.11 or newer
• System version 4.11.3 or later is required for V-430 variants with
integrated alarm devices.
• AutroGuard Protectors require AutroSafe loop panel: version 1.6
or newer
• AutroGuard Protectors require Autroprime version 2.2.0
• Loop Driver Module BSD-310/BSD-311 revision 7 or newer
Operating temperature for EN54 variants
-30 to +70 °C (+80°C when configured as heat detection only)
