Functional Description
AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339-4, 2022-12-09,
Autronica Fire and Security AS
Page 37
5.9 Protector “Alive Signal”
To indicate that the protector is “alive” (during normal operation), a
red LED blinks periodically. The blinking is configurable (ON/OFF) and
is by default OFF. See configuration, chapter 12.3.1.
When turned ON the LED will give a short blink every time the
protector is communicating with the panel (once every 90 seconds).
5.10 LED Behavior
When the protector is in operation, the following LED behavior
applies:
By default the LED is OFF when the protector is
idle. Alive pulse can be enabled.
The LED will be steady ON when the protector is
in alarm
60ms/40ms
Alternative behavior of the alarm LED indicator
activated at alarm. Can be configured ON/OFF
as a global option in the configuration tool.
The alarm LED indicator will blink once every
time it is directly addressed. Can be configured
on/off as a global option in the configuration
When the protector is in test state, the LED will
behave as follows:
• 1 time every five seconds for a smoke
detector
• 2 times every five seconds for a heat
detector
• 3 times every five seconds for a
smoke/heat detector
• 4 times every five seconds for
(Yellow LED is not yet supported).
