4.6 Integrated VAD and Sounder – Current
Consumption
The following table provides an overview of the VAD intensity and
current consumption for white and red LED indicators (Base +
Protector + VAD + Sounder). The table includes values for 0,5Hz and
1Hz, and for low and high volume. The quiescent current for VAD and
sounder is 360µA (+ 120µA for protector and base).
Technical specifications INTEGRATED VAD + Sounder
VAD Color VAD Intensity
Current
Consumption
VAD + Sounder
(LED indicator NOT
included)
0,5Hz
Current
Consumption
VAD + Sounder
(LED indicator NOT
included)
1Hz
Description
Low
Volume
High
Volume
Low
Volume
High
Volume
WHITE
High Intensity: C-3-12
23,3mA
26,9mA
-
-
At a given mounting
height, the Coverage
Volume of a VAD is defined
by the diameter of the
coverage, given in meters.
Example:
C-3-12 corresponds to a
ceiling-mounted device
giving a coverage
cylindrical volume of 12 m
at 3 m height. For a white
VAD, high intensity is to be
configured.
Medium Intensity: C-3-9
16,1mA
19,7mA
-
-
Low Intensity: C-3-6
12,9mA
16,4mA
23,1mA
26,7mA
Open Class: O-2,5-4
(specified at 2,5m height)
7,1mA
10,6mA
11,2 mA
14,8 mA
RED*
High Intensity: C-3-8
22,0mA
25,5mA
-
-
Low Intensity: C-3-5
15,1mA
18,6mA
-
-
Open Class: O-2,5-4
(specified at 2,5m height)
10,8mA
14,3mA
18,9mA
22,4mA
*Available for V-430 only.
