Accessories
AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339-4, 2022-12-09,
Autronica Fire and Security AS
Page 115
15.8 Telescope Removal Tool
The removal tool for AutroSafe protectors is used together with the
1,26m to 4,5m telescope pole.
Note that In order to use the removal tool, the protector cannot be
locked to the base. Make sure that the protector is unlocked before
attempting to remove it.
Part number 116-WBJ-220.
15.9 Ground Device
If the loop cable has a screen, a twist wire connector is required in
order to connect the in/out screens together in the protector base.
The screen must be connected to earth in one end only. This will
normally be at the panel.
