4.5 Integrated VAD – Current Consumption
The following table provides an overview of the VAD intensity and
current consumption for white and red LED indicators (Base +
Protector + VAD). The values for both 0,5Hz and 1Hz are shown.
The quiescent current for a VAD is 320µA (+ 120µA for protector and
base).
Technical specifications INTEGRATED VAD
VAD Color VAD Intensity
Current
Consumption
VAD (LED
indicator NOT
included)
0,5Hz
Current
Consumption
VAD (LED
indicator NOT
included)
1Hz
Description
WHITE
High Intensity: C-3-12
21,0mA
-
At a given mounting height,
the Coverage Volume of a VAD
is defined by the diameter of
the coverage, given in meters.
Example:
C-3-12 corresponds to a
ceiling-mounted device giving
a coverage cylindrical volume
of 12 m at 3 m height. For a
white VAD, high intensity is to
be configured.
Medium Intensity: C-3-9
13,8mA
-
Low Intensity: C-3-6
10,6mA
20,8mA
Open Class: O-2,5-4
(specified at 2,5m height)
4,8mA
8,9mA
RED*
High Intensity: C-3-8
19,7mA
-
Low Intensity: C-3-5
12,8mA
-
Open Class: O-2,5-4
(specified at 2,5m height)
8,5mA
16,6mA
*Available for V-430 only.
