Technical Specifications
AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339-4, 2022-12-09,
Autronica Fire and Security AS
Page 28
Tone 7 - DIN tone 1200-500
High volume: 90 dB(A) @ 1 m max. / 77 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
78.34
79.44
1.1
82.04
83.44
1.4
45
78.94
79.64
0.7
81.84
83.34
1.5
75
89.24
90.44
1.2
78.14
79.64
1.5
105
84.74
85.54
0.8
81.44
82.54
1.1
135
77.04
78.64
1.6
81.04
82.34
1.3
165
79.94
80.94
1
83.34
84.94
1.6
Low volume: 82 dB(A) @ 1 m max. / 70 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m
Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
71.04
71.04
0
74.24
74.34
0.1
45
71.24
71.24
0
74.34
74.44
0.1
75
81.64
81.84
0.2
70.74
70.74
0
105
77.74
77.74
0
73.64
73.74
0.1
135
69.84
70.04
0.2
73.14
73.34
0.2
165
72.74
72.74
0
75.14
75.34
0.2
