Autronica AutroGuard Multicriteria Protector V-430 Series User Manual

Technical Specifications
AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339-4, 2022-12-09,
Autronica Fire and Security AS
Page 27
Tone 3 - Continuous 3650
High volume: 90 dB(A) @ 1 m max. / 70 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m Vertical plane dB(A) @ 1 m
Vmin Vmax Diff Vmin Vmax Diff
15
79.74
80.14
0.4
81.84
81.74
-0.1
45
77.04
77.14
0.1
82.44
82.34
-0.1
75
89.74
90.04
0.3
69.94
70.54
0.6
105
86.44
86.64
0.2
81.04
81.14
0.1
135
76.94
77.04
0.1
81.24
81.14
-0.1
165
80.04
80.34
0.3
82.24
82.04
-0.2
Low volume: 90 dB(A) @ 1 m max. / 70 db(A) at 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m
Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
79.24
79.74
0.5
80.84
81.14
0.3
45
77.04
77.34
0.3
81.64
82.04
0.4
75
89.44
89.64
0.2
70.24
70.24
0
105
85.64
86.24
0.6
80.34
80.74
0.4
135
76.54
77.14
0.6
80.24
80.84
0.6
165
79.64
80.14
0.5
81.64
81.94
0.3
Tone 5 - Whoop 800-970 7 Hz
High volume: 90 dB(A) @ 1 m max. / 77 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
78.64
80.04
1.4
82.74
84.14
1.4
45
79.14
79.64
0.5
82.64
84.04
1.4
75
89.44
90.84
1.4
78.34
79.84
1.5
105
84.64
85.94
1.3
82.04
83.24
1.2
135
77.44
78.84
1.4
81.64
83.04
1.4
165
80.34
81.64
1.3
84.14
85.54
1.4
Low volume: 82 dB(A) @ 1 m max. / 70 dB(A) @ 1 m min.
Position
(degrees)
Horizontal plane dB(A) @ 1 m
Vertical plane dB(A) @ 1 m
Vmin
Vmax
Diff
Vmin
Vmax
Diff
15
71.24
71.34
0.1
73.54
74.74
1.2
45
71.64
71.64
0
73.74
74.74
1
75
81.54
81.74
0.2
69.94
70.84
0.9
105
77.44
77.54
0.1
73.14
73.74
0.6
135
69.54
69.84
0.3
72.84
73.54
0.7
165
72.94
73.04
0.1
74.64
75.64
1
