Autronica AutroGuard Multicriteria Protector V-430 Series User Manual

Visual Alarm Device (VAD)
AutroGuard Multicriteria Protector Series V-430, V-530, V-100, V110 and V-120,
AutroGuard-Technical-Handbook, Doc-1004339-4, 2022-12-09,
Autronica Fire and Security AS
Page 41
6.5.3 VAD Intensity - White VAD and Red VAD
White VAD
Red VAD
High Intensity :
C-3-12
High Intensity :
C-3-8
Medium Intensity:
C-3-9
(not applicable)
Low Intensity:
C-3-6
Low Intensity:
C-3-5
Open Class
O-2,5-4
(specified at 2,5m height)
Open Class
O-2,5-4
(specified at 2,5m height)
6.6 Flash Rate
The flash rate is configurable at 0,5Hz and 1Hz. The flash rate impacts
the light intensity and therefore the coverage volume according to
EN53-23.
1Hz flash rate is equal to one flash every second. 0,5Hz flash rate is
equal to one flash every two seconds.
The table below shows the flash rates (Hz) for different VAD intensity
settings for white and red visual alarm devices.
Provides sufficient
illumination/intensity
Not recommended, will not provide
sufficient illumination/intensity.
White Visual Alarm Device
Flash Rate
0.5 Hz
1 Hz
High C-3-12
Medium C-3-9
Low C-3-6
O-2.5-4
Red Visual Alarm Device
Flash Rate
0.5 Hz
1 Hz
High C-3-8
Low C-3-5
O-2.5-4
Refer to Configuration, chapter 12.7.7.
