9.7 Removing the Protector from the Base
Before removing a protector from a base, observe the aligment
marks to determine whether it is locked or not to the base (see
chapter 9.4).
To remove a protector that is not locked:
• Simply grab the rotatable bayonet ring and turn it counter-
clockwise, then remove the protector from the base
To remove a protector that has been locked with the locking tool:
• Grab the rotatable bayonet ring, insert and press the locking tool
into the small slot
• Turn the bayonet ring counter-clockwise, and remove the
protector from the base
9.8 Retrofit mounting onto Existing AutroSafe Base
BWA-100/BWA-101
Autronica provides several different variants of protectors specifically
intended for retrofit purposes (AutroGuard® Retro). These protectors
can easily be mounted onto an existing AutroSafe base
(BWA-100/BWA-101) similar to chapter 9.5. For dimensions, see
chapter 3.6.4.
• Remove the existing detector from the base
• Insert the retrofit protector onto the base, then turn the
protector (the bajonet ring is not rotatable on retrofit protectors)
clockwise until it is properly fastened
