Viewing the quality of your call1
XT Series endpoints display a graphical indicator representing the overall quality of each call link.2
The link quality indicator level is evaluated separately for audio, video, and presentation streams,3
based on the average packet loss percentage of the last five seconds. The worst of the three4
calculated levels is then displayed.5
Quality Average Packet Loss
Icon Level Audio Video Presentation
Excellent <=3 <=1 <=1
Good >3 >1 >1
Normal >7 >3 >3
Bad >10 >5 >5
Problematic >15 >10 >10
For example, if the overall link quality indicator level is Excellent, it means that the average packet6
loss is now less than 3% for audio, 1% for video, and 1% for presentation.7
Procedure8
• In a point to point call, the link quality indicator level is displayed in the XT Series user9
interface top header. If the level is Normal or below, it is also displayed as an alert over the10
video, when the top header is not visible.11
12
Figure 97: Top Header13
• In a multipoint call hosted by the XT Series built-in MCU, the link quality indicator level is14
displayed as overlay image on the remote participants' video. The level is also available in15
the statistics of each active call.16
Troubleshooting the Avaya Scopia
®
XT Series
December 2017 Avaya Scopia
®
XT Series User Guide 116
Avaya - Proprietary. Use pursuant to the terms of your signed agreement or Avaya policy.
DRAFT—December 15, 2017—1:33 PM (UTC)
